Powerful. Flexible. Brilliant.
Built for Everywhere Your Message Needs to be.
Introducing the Avocor B Series, a stunning range of professional displays engineered for performance, reliability, and ease of deployment.
From corporate messaging to retail promotion, the B Series powers a wide range of dynamic digital experiences designed to inform, engage, and inspire audiences.
From corporate messaging to retail promotion, the B Series powers a wide range of dynamic digital experiences designed to inform, engage, and inspire audiences.
Continuous 24/7 Operation
Built for 24/7 reliability, the display ensures uninterrupted performance in demanding commercial settings such as retail, transportation hubs, and hospitality venues.
Flexible Deployment Options
A myriad of sizes from 43" & 55", mounted portrait or landscape, giving creative freedom for any signage layout or space design.
Ultra-bright 4K Clarity
Deliver stunning, true-to-life visuals with 4K UHD resolution, 700-nit brightness and high color accuracy, perfect for high-ambient light interior environments.
Powerful, Future-Ready Performance
Equipped with an 8-core ARM processor for fast, responsive playback and long-term compatibility with evolving CMS solutions. The embedded Android 14 System-on-Chip (SoC) removes at least 3 failure points and reduces cost from every install.
遠端管理與網路化控制
可透過遙控器、RS232 或 IP 網路進行管理，輕鬆整合第三方控制系統與自動化平台，提升整體管理效率。
Remote Management & Networked Control
Manage your display via remote control, RS232, or IP, offering flexible integration with third-party control systems and automation platforms.
A CMS-agnostic Platform
The B Series displays include flexible connection options and multiple methods for integration with popular Content Management System (CMS) apps for a truly CMS-agnostic solution.
Slim Profile, ADA Compliant Design
Slim 70mm profile with even bezels create a clean, professional look that meets ADA compliance standards and adapts effortlessly to the unique demands of each environment.
Built for 24/7 reliability, the display ensures uninterrupted performance in demanding commercial settings such as retail, transportation hubs, and hospitality venues.
Flexible Deployment Options
A myriad of sizes from 43" & 55", mounted portrait or landscape, giving creative freedom for any signage layout or space design.
Ultra-bright 4K Clarity
Deliver stunning, true-to-life visuals with 4K UHD resolution, 700-nit brightness and high color accuracy, perfect for high-ambient light interior environments.
Powerful, Future-Ready Performance
Equipped with an 8-core ARM processor for fast, responsive playback and long-term compatibility with evolving CMS solutions. The embedded Android 14 System-on-Chip (SoC) removes at least 3 failure points and reduces cost from every install.
遠端管理與網路化控制
可透過遙控器、RS232 或 IP 網路進行管理，輕鬆整合第三方控制系統與自動化平台，提升整體管理效率。
Remote Management & Networked Control
Manage your display via remote control, RS232, or IP, offering flexible integration with third-party control systems and automation platforms.
A CMS-agnostic Platform
The B Series displays include flexible connection options and multiple methods for integration with popular Content Management System (CMS) apps for a truly CMS-agnostic solution.
Slim Profile, ADA Compliant Design
Slim 70mm profile with even bezels create a clean, professional look that meets ADA compliance standards and adapts effortlessly to the unique demands of each environment.
Engineered for Always-On Environments
From corporate messaging to retail promotion, the B Series powers a wide range of dynamic digital experiences designed to inform, engage, and inspire audiences.Take Control of Your Content
With the Avocor B Series, you’re never boxed in. Choose from flexible options to load and manage your content. Whether you’re plugging in a media player or syncing up with your go-to content management system. No restrictions, no complicated workarounds. Just a display that works the way you do.| Display Model | AVB-4310A | AVB-5510A |
| Size | 43” | 55” |
| Backlight | Direct LED | |
| Aspect Ratio | 16:9 | |
| Resolution | 4K (3840 x 2160) | |
| Response Time | 6.5ms | |
| Brightness | 700nit | |
| Contrast Ratio | 4000 : 1 | |
| Viewing Angle | 178° / 178° | |
| Display Colors | 1.07G (8 Bit+FRC) | |
| Operating Hours | 24 hours x 7 days | |
| Orientation | 橫向 / 直立 | |
| Glass | 防眩光 霧度 25% | |
| CPU | ||
| CPU | Cortex A72*4 + Cortex A53*4 | |
| GPU | ARM Mali G52 MC3 GPU | |
| RAM/ROM | 8G RAM / 32G ROM | |
| Android Version | Android 14 | |
| Connectivity | ||
| Inputs | 2 x HDMI (2.0), 1 x USB-A 3.0, 1 x USB-B (Service port) | |
| Outputs | 1 x HDMI 2.0 Out (Supports 4K @ 60Hz, 1920 x 1080 @ 60Hz) | |
| Audio Output | 1 x S/PDIF Out (Opt), 1 x 3.5mm (Line Out) | |
| Control | RJ45 LAN (1/100/1000Mbps) + RS232 (DB9 female) | |
| WiFi | WiFi 5 2.4/5GHz | |
| Audio | ||
| Built-in Speakers | 2 x 10W | |
| Display & Remote Features | ||
| Auto Source Detection | Yes | |
| Image Settings | Yes | |
| Physical Specs | ||
| Physical Dimensions(WxHxD) | 971 x 559.5 x 70.0mm | 1238.4 x 709.2 x 69.8mm |
| Bezel Width | 13mm | 12.9mm |
| Packing Dimensions(WxHxD) | 1075 x 652 x 144mm | 1390 x 830 x 144mm |
| Net Weight | 8.85kg | 13.85kg |
| Gross Weight | 11.5kg | 18.5kg |
| VESA Mount（VESA） | 300 x 300mm M6 x 18mm | 400 x 400mm M6 x 18mm |
| Power | ||
| Typical Consumption | 125W | 140W |
| Max Consumption | 175W | 215W |
| Environmental Specs | ||
| Operating Temperature | 0°C - 40°C | |
| Storage Temperature | -20°C - 55°C | |
| Humidity | 20% - 80% | |
| Accessories | ||
| Included Accessories | Remote control, batteries, quick start guide, AC power cord, HDMI cable (3m), wall mount bracket | |
* Specifications and equipment are subject to change without prior notice.
